DRUCK Pressure Indicator / loop calibrator - DPI802

Part #: DPI802S - Standard Accuracy Single Range

The DPI 800 Series provides a complete range of advanced, robust and simple to use hand-held instruments. Highly cost effective, these tools are ideal for test/calibration of many popular process parameters. Advanced features address more applications in less time and deliver results

you can rely on.

Features:

• Ranges from 25 mbar to 700 bar (10 in H2O to 10,000 psi)
• Single or dual range configuration
• mA measure, switch test and 24V loop power
• Large backlit display, menu driven interface
• HART® loop resistor
• Robust and weatherproof
• Compact, simple to use, easy to carry
• Convenient, one-handed operation
• Secure grip, impact resistant, elastomer protected
• Plug and play IUPM/IUPMP (IDOS) universal pressure modules provide accuracies to 0.05% FS all inclusive or 0.01% precision

Choose pressure range and type from:

• 25, 70, 200, 350 or 200mbar - Gauge or Differential
• 350mbar - Absolute
• -1 to 2 bar - Gauge and Differential
• 2 bar - Absolute
• -1 to 3,5, 7, 10 or 20bar - Gauge
• 7,20 bar - Absolute
• 35,70,100,135,200bar - Gauge
• 350 or 700bar - sealed Gauge
